CR10-28 Chromium Containing Cast iron grinding media iron balls for cements
CR10-28 Chromium Containing Cast iron grinding media iron balls for cements
1）Uniform hardness
2）Low breakage rate
3）High grinding resistance
4）High impact value
CR10-28 Chromium Containing Cast iron grinding media iron balls for cements
Shandong Jinchi Heavy Industry Joint-stock co.,ltd ,which manufacture media balls are used in mining companies like gold mine, copper mine, zinc mine, iron mine etc.Till now, we have supply to Ghana, Mexico, Canada, South africa, Chile, Peru, Congo, Zambia and so on. Our products have received good feedback from customers in different industry.
Casting balls chemical composition:
Chemical Components | ||||||||
Type | Chemical components | |||||||
C | Si | Mn | Cr | Mo | Cu | P | S | |
Low-Cr | 1.8-3.3 | ≤1.5 | 0.3-1.5 | 1-3 | ≤1.0 | ≤0.8 | ≤0.10 | ≤0.10 |
Medium-Cr | 1.8-3.3 | ≤1.2 | 0.3-1.5 | 4-9 | ≤1.5 | ≤0.8 | ≤0.10 | ≤0.10 |
High-Cr | 1.8-3.3 | ≤1.2 | 0.3-1.5 | 10-18 | ≤1.0 | ≤1.2 | ≤0.10 | ≤0.06 |
Superhigh-Cr | 1.8-3.3 | ≤1.2 | 0.3-1.5 | 19-35 | ≤2.0 | ≤1.2 | ≤0.10 | ≤0.06 |
Forged grinding balls chemical composition:
Brand | Materials | C | Mn | Si | Cr | S | P | V |
JC-1 | 50Mn | 0.48-0.56 | 0.70-1.0 | 0.17-0.37 | ≤0.25 | ≤0.035 | ≤0.035 | |
JC-2 | 60Mn | 0.57-0.65 | 0.70-1.0 | 0.17-0.37 | ≤0.25 | ≤0.035 | ≤0.035 | |
JC-3 | 65Mn | 0.62-0.70 | 0.90-1.2 | 0.17-0.37 | ≤0.25 | ≤0.035 | ≤0.035 | |
JC-4 | B2 | 0.72-0.85 | 0.70-0.80 | 0.17-0.37 | 0.40-0.70 | ≤0.035 | ≤0.035 | |
JC-5 | B3 | 0.58-0.70 | 0.70-1.00 | 1.50-1.90 | 0.70-0.90 | ≤0.035 | ≤0.035 | |
JC-6 | B6 | 0.80-0.95 | 0.80-1.00 | 0.17-0.37 | 0.80-1.00 | ≤0.035 | ≤0.035 |
Product Features of forged and casting grinding media ball
Uniform hardness
Non crushing and grinding resistance
High impact value
