4” Forged Grinding Steel Ball
4" Forged Grinding Steel Ball
(1)Uniform hardness
(2)Unbreakable
(3)High wear resistance
(4)High impact value
(5)High combined efficiency of grinding mill
4”Forged Grinding Steel Ball
Shandong Jinchi Heavy Industry Joint-stock Co.,LTD is a professional manufacturer of 4” Forged Grinding Steel Ball products.from CHINA , specialized in providing wear-resistant solutions for the mining /cement /power/coal/ construction /chemical industry, in-depth 27 years of industry.We Supply different countries with IS09001 Quality Certification, OHSAS 18001 Occupational health and safety certification and ISO14001 environmental management system certification.
1)Uniform hardness
2)Unbreakable
3)High wear resistance
4)High impact value
5)High combined efficiency of grinding mill
Materials | C% | Si% | Mn% | P% | S% | Cr% |
B2 | 0.70-0.85 | 0.17-0.37 | 0.70-1.00 | ≤0.035 | ≤0.035 | 0.4-0.6 |
B2-1 | 0.55-0.70 | 0.15-0.30 | 0.65-0.85 | ≤0.020 | ≤0.020 | 0.70-1.10 |
High Carbon B2 | 0.85-1.10 | 0.15-0.45 | 0.40-1.20 | ≤0.035 | ≤0.035 | 0.20-1.10 |
B3 | 0.58-0.66 | 1.70-1.90 | 0.68-0.80 | ≤0.030 | ≤0.030 | 0.78-0.90 |
45# | 0.42-0.50 | 0.17-0.37 | 0.5-0.8 | ≤0.035 | ≤0.035 | 0.25max |
B4 | 0.65-0.75 | 1.20-1.40 | 0.50-0.70 | ≤0.025 | ≤0.025 | 0.85-1.00 |
B6 | 0.75-0.90 | 0.17-0.37 | 0.8-1.02 | ≤0.035 | ≤0.035 | 0.88-0.98 |
B6-1 | 0.82-0.90 | 0.15-0.35 | 0.90-1.05 | ≤0.020 | ≤0.020 | 0.88-0.98 |
BU | 0.95-1.05 | 0.15-0.35 | 0.95-1.05 | ≤0.025 | ≤0.025 | 0.45-0.55 |
1090 | 0.90-1.10 | 0.17-0.37 | 0.60-0.90 | ≤0.025 | ≤0.025 | ≤0.025 |
42CrMo | 0.38-0.45 | 0.20-0.40 | 0.50-0.80 | ≤0.035 | ≤0.035 | 0.90-1.20 |
40Cr | 0.37-0.45 | 0.20-0.40 | 0.50-0.80 | ≤0.035 | ≤0.035 | 0.80-1.10 |
65MN | 0.62-0.70 | 0.17-0.37 | 0.90-1.20 | ≤0.035 | ≤0.035 | ≤0.25 |
60MN | 0.57-0.65 | 0.17-0.37 | 0.70-1.00 | ≤0.035 | ≤0.035 | ≤0.25 |
50MN | 0.48-0.56 | 0.17-0.37 | 0.70-1.00 | ≤0.035 | ≤0.035 | ≤0.25 |
Diameter Tolerance(mm) | Surface Hardness(HRC) | Impact Toughness(j/cm2) | |
Φ20 | +2, —1 | >60HRC | ≥12 |
Φ25 | |||
Φ30 | |||
Φ40 | |||
Φ50 | |||
Φ60 | +3, —2 | ||
Φ70 | |||
Φ80 | |||
Φ90 | |||
Φ100 | +4, —2 | ||
Φ110 | |||
Φ120 | >58HRC | ||
Φ130 | |||
Φ140 | +4, —3 | >55HRC | |
Φ150 |
Shandong Jinchi Heavy Industry Joint-stock Co.,LTD is looking forward to cooperating with you to create a better future!
