Grinding Media Ball

Specifications

1. Grade: 45#,50Mn,60Mn,65Mn,B2,B3,BL,BG

2. Diameter: 15mm-150mm

3. Hardness: HRC 55-65

4. Breakage Rate:<1%

5. Impact Value: >12j/Cm^2

6. Falling ball times: ≥20000s


  Contact Now E-Mail Telephone WhatsApp
Product Details

Shandong Jinchi Heavy Industy Joint-stock Co.,Ltd, is a professional manufcture of grinding steel balls in China.Our company has been committed to producing grinding steel balls, forged steel balls, grinding rods and other products for over 20 years . And we  have passed ISO9001: 2008 Quality Management System certification.  we can also produce grinding balls fully meet customer needs according to their specific requirements.

1)Grinding ball:size: DIA 20mm to DIA 150mm;

2)grinding rods:Dia40-120mm,length can be done according to request of clients.


grinding media ball


· Mining industry - grinding of ores (gold, sliver, copper, iron, manganese, chromium, wolfram, molybdenum, zinc, )

· Building industry - grinding of sand and raw materials for cement (limestone) production

· Power engineering - grinding of coal, blast furnace slag, etc.

· Other - grinding of colour pigments, ceramic materials, etc.




Materials

C%

Si%

Mn%

P%

S%

Cr%

B2

0.70-0.85

0.17-0.37

0.70-1.00

≤0.035

≤0.035

0.4-0.6

B2-1

0.55-0.70

0.15-0.30

0.65-0.85

≤0.020

≤0.020

0.70-1.10

High Carbon B2

0.85-1.10

0.15-0.45

0.40-1.20

≤0.035

≤0.035

0.20-1.10

B3

0.58-0.66

1.70-1.90

0.68-0.80

≤0.030

≤0.030

0.78-0.90

45#

0.42-0.50

0.17-0.37

0.5-0.8

≤0.035

≤0.035

0.25max

B4

0.65-0.75

1.20-1.40

0.50-0.70

≤0.025

≤0.025

0.85-1.00

B6

0.75-0.90

0.17-0.37

0.8-1.02

≤0.035

≤0.035

0.88-0.98

B6-1

0.82-0.90

0.15-0.35

0.90-1.05

≤0.020

≤0.020

0.88-0.98

BU

0.95-1.05

0.15-0.35

0.95-1.05

≤0.025

≤0.025

0.45-0.55

1090

0.90-1.10

0.17-0.37

0.60-0.90

≤0.025

≤0.025

≤0.025

42CrMo

0.38-0.45

0.20-0.40

0.50-0.80

≤0.035

≤0.035

0.90-1.20

40Cr

0.37-0.45

0.20-0.40

0.50-0.80

≤0.035

≤0.035

0.80-1.10

65MN

0.62-0.70

0.17-0.37

0.90-1.20

≤0.035

≤0.035

≤0.25

60MN

0.57-0.65

0.17-0.37

0.70-1.00

≤0.035

≤0.035

≤0.25

50MN

0.48-0.56

0.17-0.37

0.70-1.00

≤0.035

≤0.035

≤0.25


Grinding ball info

Item

Forging steel grinding balls

Sizes

20mm-150mm

Grade

45#, 50Mn, 60Mn, 65Mn, B2, B3, BL, BG

Hardness

Surface: 55-60HRC / Core: 45-60HRC

Certification

TUV ISO9001, SGS

Material

Alloy Steel

Breakage rate

25mm--80mm  0.5%       90mm-140mm  1%

Out of roundness

1%

Impact toughness

>12AK.j/cm^2



Packing Details

a. steel drums (850-900kgs/drum)    b. flexible container bags(1ton/bag)

Delivery Details

Within 15-20 days after received the payment or LC at sight
